Features:

1. Small size, lightweight, easy to Carry.
2.Automatic storage of exposure parameters, only one exposure, can be permanent memory.
3.High brightness LCD display, various functions are clear at a glance.
4.Remote control or handbrake switch can be selected to make the operation more convenient.
5.Tooth tablet or sensor can be selected to make the imaging clearer.
6.Large capacity rechargeable battery, once charged, can be used for a long time.
7.High frequency power supply, low radiation, beautiful appearance.
8.Clear room irrigation, one-minute imaging, immediately used tor diagnosis.
9.Mobile Support is optional.

In usage:

1. Ensure that the device user is well trained.

2. Pregnant women should ask your doctor before photographing.

3. Exposure to too much exposure ray can cause minor damage to the human body.

4. Recommended storage humidity: 10 ~ 75% RH.

5. Recommended humidity: 15 ~ 70% RH.

6. Recommended storage temperature: 10 ~ 40 ° C.

7. Recommended usage temperature: 10 ~ 35 ° C.

8. Optimum temperature range: 10 ~ 30 ° C.



Specifications:

Tube Voltage	60KV
Tube Current	1.5mA
Rated power	60VA
Focus Size	0.8/0.4
Battery Voltage /Capacity	14.8V 4400mAh
Charger Input Voltage	AC110-220V 50/60Hz
Exposure time	0-2.5s
The distance from the collimator tube to the skin	110 mm
Frequency	30KHz
Ambient temperature	5℃~ 40℃
Relative humidity	<75%RH
Net weight	2.6KG
Gross weight	3.5KG
Size (mm)	190*140*150

Others:

1. If any problem and error that cannot be solved occurs, please stop using it immediately and

contact the specified manufacturer.

2. Due to internal high-pressure X-ray, please do not open or modify the device without consent.

Improper usage will cause harm to users and patients.

3. Do not allow non-professionals to use or repair the device.

4. Please charge the device in the allowable range of AC100-240V.

5. Do not touch the device or its conductive part with wet hands.

6. Use of a non-standard charger will damage the battery.

7. Do not discard used battery at will, put it into the designated recycling bin instead.

8. Battery is a consumable, so each device is only equipped with only one original battery. For

purchase, please contact the manufacturer.



Packing list

host machine 1

Charger 1

Manual 1
