KS-XR563 X-ray Sensor

X-ray Sensor UK Ateco
  • Product Detail

Features

1. The whole cable is made of medical grade flame fire-retardant PU material. Good tensile   resistance, antibacterial  and protecting ultrafine conductive wire core. Long lifetime and durable in   use.
2. Waterproof design, can be wiped disinfection
3. CMOS technology, low power consumption. The lifetime of professional clip is more than   500,000 times, providing more durability and compatible with all kinds of X-ray machine.
4. The high identify ability of detais and low x-ray dose helps you to diagnose the tooth lesion   problems, making more accuracy.
5. Providing professional connectivity solutions. All the information can be viewed in different   locations.
6. The scintillator ma kes high-definition images.
7. Fast imaging employing steady acquisition, saving the filing time and improving work efficiency.
8. Professional image management software to help you manage images easily and efficiency.
9. Two years warranty. Free to use our latest software for life.

Item:

AT-303

Image Pixel:

1.9M(1600*1200)

Pixel size:

18.5um

Chip Type:

CMOS APS

Fiber Optical Plate:

Yes

Scintillator:

Gos

Resolution(lp/mm):

Theoretical value: 27lp/mm;    Actual value: 12-14lp/mm(GOS)

Operation system:

Windows2000/xp/Win7/Win8(32bit&64bit)

Dimension:

27.5x38.5mm

Active:

22.5x30mm(675mm²)

Additional:

TWAIN Driver

PREVIOUS:KS-XR562 x-ray sensor

NEXT:KS-XR565 X-ray Sensor
